Disposable Tocar
The company has a 28,000 square meters clean production plant, in accordance with GMP standards to produce pharmaceutical packaging materials and medical instruments.
Product Category:
Key words:
Email:
Disposable Tocar
【Features】
1.Two sealing system
-Umbeliform gland bush achieve excellent sealing performance.
-Universal sealing cap,compatible with 4.8-12.9Mm instruments.
2.Excellent air tightness,with a leakage rate of <0.5L/min at 4KPa pressure.
3.Removable seal cap for easy larger specimen retrieval.
4. Cannula bodly adopts stainless steel material to ensure the hardness in the operation.
5. Densely barbed threaded design maximizes abdominal wall retention, preventing trocar sleeve dislocation during the operation.
6. Optical tip provides direct visualization and eliminates blind entry. Separates, rather than cuts, along tissue fibers, pushing tissue and vessels away to achieve a low rate for incisional hernis.
7. Optical blunt tip and black-coded line for preventing damage on the viscera.
8. Patented design on the obturator tip with scratching function ensures a clear visualization during operation, when the lens is stained with blood, there is no need to wipe the lens repeatedly, shortening the operation time.
Model |
Description |
HR5ML |
Cannula+Obturator (5*100mm),large |
HR12ML |
Cannula+Obturator (12*100mm),large |
HR15ML |
Cannula+Obturator (15*100mm),large |
HR5MX |
Cannula+Obturator (5*120mm),middle |
HR12MX |
Cannula+Obturator (12*120mm),middle |
HR15MX |
Cannula+Obturator (15*120mm),middle |
HR5MS |
Cannula+Obturator (5*75mm),small |
HR12MS |
Cannula+Obturator (12*75mm),small |
HR15MS |
Cannula+Obturator (15*75mm),small |
Trocar-set |
HR12ML |
HR5ML |
I |
2Cannula+Obturator (12*100mm) |
Cannula+Obturator (5*100mm) |
II |
Cannula+Obturator (12*100mm) |
2Cannula+Obturator (5*100mm) |
III |
2Cannula+Obturator (12*100mm) |
2Cannula+Obturator (12*100mm) |
IV |
Cannula+Obturator (12*100mm) |
3Cannula+Obturator (12*100mm) |
V |
|
3Cannula+2Obturator (12*100mm) |
VI |
3Cannula+Obturator (12*100mm) |
|
